H frame gantry Hydraulic press
This robust and versatile H frame gantry Hydraulic press is designed for multi-functional operations on mechanical parts, offering efficiency and precision across a wide range of applications.
The H frame gantry Hydraulic press can perform a diverse range of operations, including:
--Assembling and disassembling components
--Straightening rolls and correcting deformities
--Stretching and bending metal parts
--Punching operations for both light and heavy-duty tasks
Technical parameters
|
Specification
|
Unit
|
40T-A
|
40T-B
|
|
|
Nominal force
|
KN
|
200
|
200
|
|
|
Gantry span
|
mm
|
520
|
520
|
|
|
Working table size
|
mm*mm
|
460*400
|
460*400
|
|
|
Down speed
|
mm/s
|
6.5
|
14
|
|
|
Return speed
|
mm/s
|
9.5
|
19
|
|
|
Motor power
|
KW
|
3
|
5.5
|
|
🔩 Advanced Table & Structure Design
The adjustable worktable allows upward movement and height adjustment, making it more convenient for operators to access different sizes and shapes of workpieces.
The gantry-style H-frame structure offers superior stability and strength for high-precision pressing tasks.
Hydraulic Press System
💧 Efficient Hydraulic System
The hydraulic transmission system is positioned at the side of the machine, providing reliable control over the slider's movement.
Equipped with an integrated two-way cartridge valve block, the system ensures:
* Fast response speed
* Large oil flow capacity
* Low flow resistance
* Reliable operation
* Ease of maintenance
The power source uses a CY high-pressure variable axial piston pump for high flow and pressure control.
🛠️ Durable Hydraulic Piping & Safety Features
All large-diameter pipes are connected using flange joints, ensuring shock resistance and leak-proof operation. The hydraulic oil tank is equipped with:
* An oil filtration device
* A liquid level display
* A top-mounted filler tank for easy maintenance and monitoring
Application
This hydraulic press is ideal for both metal and non-metal materials, including:
● Watches and hardware
● Bicycles, motorcycles, and automotive components
● Tableware and kitchenware
● Electrical appliances and rubber
● Buttons, ceramics, and powder metallurgy
● Gold and silver jewelry
● Grinding wheels and plastic materials
Whether you're forming, stamping, or molding - this H frame gantry Hydraulic press delivers consistent and professional-grade results.
