PRODUCT DESCRIPTION
An innovative machine, expertly designed to produce brake pads for all types of steam turbine vehicles. Its ergonomic construction features a cleverly designed upper structure for the main oil cylinder, allowing operators to stand comfortably on the ground while comfortably managing the brake pads. Cleverly designed overhead structure for the main oil cylinder, allowing operators to stand comfortably on the floor while comfortably managing the brake pads This space-saving design not only optimises the floor plan, but also facilitates effortless workshop cleaning and maintenance.
pRODUCT pARAMETER
| UP Series | LD-UP100T | LD-UP150T | LD-UP200T | LD-UP300T | LD-UP400T |
Claping Force |
1000KN | 1500KN | 2000KN | 3000KN | 4000KN |
Clamping Stroke |
350mm | 350mm | 350mm | 350mm | 350mm |
Rapid Clamping Speed |
≥60mm/s | ≥60mm/s | ≥60mm/s | ≥60mm/s | ≥60mm/s |
Heating Plate Size |
350*400mm | 450*500mm | 500*600mm | 500*600mm | 610mm*630mm |
Heating Plate Spacing |
450mm | 450mm | 450mm | 450mm | 450mm |
Rapid Cylinder Pressure |
50KN | 50KN | 63KN | 63KN | 80KN |
Release Cylinder Pressure |
50KN | 50KN | 63KN | 80KN | 100KN |
Motor Power |
5.5KW | 5.5KW | 7.5KW | 7.5KW | 7.5KW |
Heating Power |
8.4KW | 10.8KW | 18.6KW | 18.6KW | 20.4KW |
External Dimension |
1.5*1.5*1.9M | 1.5*1.6*2.0M | 1.6*1.7*2.3M | 1.6*1.7*2.4M | 1.8*1.8*2.6M |
OUR ADVANTAGES
1. Our factory has specialised in the independent R&D and production of hydraulic presses for over 15 years. The machine performance is stable and quality is excellent.
2. Our factory can provide a complete set of production line services, such as molds, process technology and other related machinery.
3. Customized hydraulic presses ranging from 5T to 1000T.
4.We provide good after-sale service.
FAQ
Q1.How to choose the most suitable machine?
A1: Please tell me your specification and parameters, we can choose the best model for you. You can also send us the product drawings and we will choose the most suitable machine for you.
Q2.What is your minimum order quantity?
A2: 1 unit. (Only some low cost machines will be more than 1 unit)
Q3: What are your payment terms?
A3: T/T, 30% initial payment at the time of order, 70% balance payment before shipment;
Irrevocable letter of credit at sight.
