Rubber Vulcanizing Press

1. Smart Structural Design
2. Precise Pressure Control
3. Intelligent Temperature Control

Send Inquiry

Description

Rubber Vulcanizing Press

The Rubber Vulcanizing Press is a high-performance press used for the vulcanization and molding of rubber products. It is a key piece of equipment across industries in manufacturing:

-Tires

-Rubber seals and gaskets

-Hoses and tapes

-O-rings and custom rubber parts

From automotive to industrial applications, this Rubber Vulcanizing Press ensures uniform, high-quality vulcanization with excellent reliability and precision.

Products parameters

Type	XLB-D/Q400×400×2E	XLB-D/Q600×600×2D	XLB-D/Q750×850×2
Nominal clamp mould force	0.5	1.0/1.6	1.6
Specification of the hot plate	400×400	600×600	750×850
Number of working layers	2	2	2
Piston diameter	Ф200	Ф300/ф320	Ф360
Max stroke of the piston	250	350/450	500
The Distance between the hot plate	125	150	150
Unit area pressure of the hot plate	3.1	3.1	3.1
Motor power	1.5	2.78/4.44	2.5
weight	1300	2600	5000
Overall size	1500×750×1500	2000×700×1700	2550×960×2100
Close the mould speed	≥12	≥12	≥12
Open mould speed	≥12	≥12	≥12

1. Smart Structural Design
-- Frame-style body with high rigidity
-- Minimal deformation under high mold-closing forces
-- Supports large-diameter hydraulic cylinders

2. Precise Pressure Control
-- High-powered hydraulic system ensures stable and accurate pressure
-- Uniform clamping force for consistent molding results

3. Intelligent Temperature Control
-- Options for steam or electric heating
-- Advanced insulation and double closed-loop control for precise temperature regulation
