Products Description
1.Main Performance Characteristics:
The 400-ton, 4-post double-action molding hydraulic press allows the work pressure, pressing speed, and travel range to be adjusted within the specified range based on requirements. It can achieve both constant pressure and constant stroke operation modes.
When forming with constant pressure, the press holds pressure for a specified time before automatically returning the stroke. A top-out device is located in the center of the working table. In addition to top products, this device can also be used as a hydraulic cushion for the forming process of drawn parts.
parameters
|
Type |
Unit |
63T |
100T |
160T |
200T |
315T |
630T |
1000T |
2000T |
|
Ejecting force |
KN |
100 |
200 |
250 |
400 |
630 |
1000 |
1200 |
2000 |
|
Nominal pressure |
KN |
630 |
1000 |
1600 |
2000 |
3150 |
6300 |
10000 |
20000 |
|
Slider Stroke |
mm |
500 |
500 |
500 |
700 |
800 |
900 |
900 |
1400 |
|
Max.opening height |
mm |
700 |
900 |
900 |
1120 |
1250 |
1500 |
1500 |
1600 |
|
Ejecting Stroke |
mm |
160 |
200 |
200 |
250 |
300 |
300 |
400 |
450 |
|
Power of motor |
KW |
5.5 |
7.5 |
15 |
18.5 |
22 |
45 |
68 |
134 |
|
Max.Working pressure |
Mpa |
25 |
26.2 |
26 |
25 |
25 |
26 |
26 |
27 |
|
Table size(F.B.) |
mm |
500 |
580 |
800 |
900 |
1200 |
1500 |
1600 |
2000 |
|
Table size(L.R.) |
mm |
500 |
710 |
800 |
900 |
1200 |
1500 |
1600 |
2800 |
|
Idle stroke |
mm/s |
76 |
100 |
100 |
100 |
＞100 |
＞100 |
＞100 |
＞100 |
|
Pressing |
mm/s |
10 |
8-15 |
8-15 |
8-15 |
8-15 |
10 |
12 |
10 |
|
Return |
mm/s |
60 |
60 |
60 |
70 |
70 |
65 |
80 |
＞75 |
|
Total Weight |
T |
2.5 |
4 |
7 |
12 |
15 |
38 |
48 |
145 |
Application
400 ton 4 post double action machine molding hydraulic press For Stretching, such as stamping, bending, flanging sheet stretching, and can be engaged in correction, press fit, plastic products, powder products, compression molding.
FAQ
Q1.When can I get the price ?
A1:We usually offer the quotation within 8hours, For urgent offer, please contact with us for special.
Q2.What is the Trade Term?
A2: We accept Ex-work factory , FOB Dalian, CNF or CIF, as your requirement.
Q3.How long is our Production leading time?
A3: It depends on type of equipment.
We often deliver the goods within 35days.
Q4.What is the Payment term?
A4: By T/T before shipment or By L/C at sight.
Q5. During shipping, if there is a damage to products, how do you get replacement?
A5: Firstly, we should investigate the reason cause the damage. At the same time, we will claim for the insurance by ourselves or assist the buyer.
Secondly we will send the replacement to the buyer. The responsible person for above damage will take charge of the cost of the replacement.
Q6. What are your terms of packing?
A6: Packing: export worthy package suitable for container transportation.
Wooden case, iron pallet, plastic film ect.
Q7. Do you test all your goods before delivery?
A7: Yes, we have 100% test before delivery.
Q8: What is your warranty?
A8: Warranty: 24 months after commercial running or 18months from the date of shipment, subject to the earlier expiry.
Q9: Can you arrange thirty party pre-shipment inspection?
A9: Pre-shipment inspection: Supplier's pre-shipment inspection is Final; pre-shipment inspection by third Party on buyers cost.
Q10:Can we do our OEM logo?
A10:Yes, for the products with drawing supplied by you, we of course apply your logo
