Product Parameter
|
Name |
Data |
|
Main motor rated output power |
3.1kw |
|
Voltage |
220v/380v |
|
Feed motor rated output power |
0.4kw |
|
Rotation speed |
50-255rpm |
|
Speed mode |
Stepless speed |
|
Axial feeding mode |
Auto/Manual |
|
Axial feed speed |
0.01-0.5 |
|
Axial feed single stroke |
280mm |
|
Boring bar diameter |
50mm |
|
Boring bar length |
1600mm |
|
Cutting thickness |
0.02-8mm |
|
Ovality tolerance |
±0.02mm |
|
Taper tolerance |
±0.01mm |
|
Ra |
3.2 |
|
Welding bar diameter |
40mm |
|
Welding thickness |
3-4mm |
|
Welding wire length |
4540mm |
|
Welding bar length |
200mm/240mm/350mm/800mm |
|
Welding bar assembly total length |
1400mm |
|
Applicable MIG welding machine |
200-500 type |
|
Applicable welding wire diameter |
0.8mm/1.0mm/1.2mm |
|
Welding function |
Spiral Welding, Sector Welding, Jump Welding |
Products Description
1.The Portable Journal Lathe is a portable shaft-turning lathe, primarily used for machining the outer diameter of a shaft to meet required specifications for concentricity, surface finish, and circularity tolerance.
2.Versatile Operation: It can operate both horizontally and vertically, and is capable of accurately machining bearing journals and other circular surfaces.
Product Advantages
1.Compact and Lightweight: It is small in size, lightweight, and excels at both boring and welding.
2.Portable and Easy to Use: No special environmental conditions or space requirements are needed, and it is easy to carry.
3.Widely Used for Repairs: It is commonly used to repair round holes, such as pin holes and bearing holes, in large-scale equipment and machinery.
FAQ
1. Q: What is your payment terms?
A:Our payment term is 30% T/T in advance, 70% T/T before shipment. It is negotiable.
2. Q: What is your delivery time?
A:Usually, one machine takes 20-40 days. If we have in stock, we can arrange
shipment as soon as we receive the payment.
3. Q:Can we go to your factory and learn how to use the machine?
A:We sincerely welcome you come to our factory.
4. Q: Do you have CE certification?
A:yes, we have CE certification, machine quality is guaranteed.
5. Q:Can you accept OEM order?
A:Sure,we accept OEM with your logo print on the machine and package with your design.
